Nvidia's next-generation Ampere graphics cards will likely use the new connection in some capacity.

(Image credit: Nvidia)

A new 12-pin PCIe power adapter purportedly set to be used with the Nvidia Ampere generation graphics cards has been confirmed by a power supply manufacturer. The new connector takes a 2x8-pin power direct from the PSU and shrinks it down into a single 12-pin connector.

What wasn't clear from the initial rumours, and not made obvious until Andreas Schilling over at HardwareLuxx received a Seasonic-made connector, is the scale of this new 12-pin configuration. It's considerably smaller than a 2x8-pin connection, and nearly occupies the same footprint as a single 8-pin connector.

Seasonic officially calls the new connector the "Nvidia 12-pin PCIe Molex Micro-Fit 3.0 Connector", which suggests this is the very same proprietary connector designated for the next-generation Nvidia graphics cards, assumedly the RTX 30-series.

It's assumed that Nvidia's Founders Edition cards will be the only ones to initially use the brand new connector, although there has so far been no official confirmation on its end use.

There's also no word on how the connector, or compatible adapters, will be distributed to users. It's likely all cards that require its use will come with an adapter cable. However, that cable may have to be an extension, and not direct to the PSU, as not all PSUs follow the same pin configuration.

Your next upgrade

(Image credit: Future)

Best CPU for gaming: the top chips from Intel and AMD
Best graphics card: your perfect pixel-pusher awaits
Best SSD for gaming: get into the game ahead of the rest

A traditional 8-pin PCIe connector (or 6+2-pin) features three +12V pins and five ground pins, and is able to deliver 150 watts per connector to a graphics card.

HardwareLuxx reports that the new 12-pin connector comes with six +12V pins, four ground, and two Sense pins (used to indicate what configuration the connector is being used in, in order to adjust power delivery accordingly (as is the case with 8-pin and 6-pin connectors).

As listed on the exterior of the box, the Seasonic power connector recommends a PSU capacity of 850W or more for use with the cable—and one would assume the graphics card to go with it.

With Intel also looking to reshape the gaming PC power with the ATX12VO specification, which takes the burden of 3.3V and 5V conversion off the PSU and integrates it into the motherboard, we could see a significant shake-up in the ageing connection and power standards that have ruled PCs for decades. Although it may be some time before the whole industry follows suit.
